Technical details:

Summary:

Thyristorsteller: 12V – 560V, 50kW
Aktives Frontend: Control techniques SP4403 (max. 800V, 55kW)

Summary:

Inverter: Semikron SKAI 45 A2 GD12-WQI or customer inverter Load machine: Siemens 1PV5135-4WS14 (max. 300 Nm, max. 10,000 rpm) Electrical power measurement: Yokogawa WT 500 -> direct 3-phase power measurement of the electrical machine, current/voltage harmonics measurable Other measurements: Current (max. 600 A), voltage, torque (max. 300 Nm), speed, mechanical power, temperatures, vibrations Geometry: Maximum shaft height: 225 mm (more on request) Cooling: Water cooling, max. 25 l/min, temperature adjustable 30 – 60°C ( /-3K)

Summary:

Inverter: Semikron SKAI 45 A2 GD12-WQI or customer inverter Load machine: Siemens 1PV5135-4WS24 (max. 400 Nm; max. 10,000 rpm) Electrical power measurement: Yokogawa WT 500 -> direct 3-phase power measurement of the electrical machine, current/voltage harmonics measurable Other measurements: Current (max. 600 A), voltage, torque (max. 2000 Nm), speed, mechanical power, temperatures, vibrations Geometry: Maximum shaft height: 225 mm (more on request) Cooling: Water cooling, max. 25 l/min, temperature adjustable 30 – 60°C ( /-3K)
